| Processor: | Intel® AtomTM Singal-core D425 processor mounted onboard |
| Chipset: | Intel? NM10 |
| Front Side Bus: | |
| Memory: | DDR3 800 MHz x 2 DIMM, Max. 4GB |
| VGA on Die: | Integrated Intel? GMA 3150 |
| Expansion Slots: | 1* PCI |
| IDE: | N/A |
| Serial ATA(SATA)/RAID: | 2* SATA II |
| Audio: | 5.1 channel HDA |
| LAN: | Gigabit LAN |
| IEEE1394: | N/A |
| Back Panel I/O Ports: | 1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x Serial port 1 x Parallel port 1 x Audio jack supports 3 jacks 4 x USB 2.0 ports 1 x RJ45 LAN port 1 x VGA port |
| Internal I/O Connectors: | 1 x ATX 24-pin power connector 1 x ATX 4-pin 12V power connector 2 x 4-pin CPU / System fan connectors 1 x IrDA header 1 x TPM header 1 x COM header 2 x USB 2.0 header supports additional 4 ports 2 x Serial ATAII connectors 1 x Front panel connector 1 x Front Audio header 1 x S/PDIF out header 1 x Buzzer |
| BIOS Features: | 8MB flash EEPROM w/ LAN boot PnP, ACPI, WfM, DMI 2.0 |
| Standards/Manageability: | PCI 2.3, USB2.0, DMI 2.5 |
| Form Factor: | Mini-ITX (6.75 inch x 6.75 inch) |
