| CPU | Intel® CPU on BoardIntegrated dual-core Intel® Atom™ processor D525 |
| Chipset | Intel® NM10 |
| Memory | 2 x DIMM, Max. 4 GB, DDR2 800/667 Non-ECC,Un-buffered MemorySingle Channel memory architecturePlease refer to[url=]www.asus.com[/url]or user manual for Memory QVL. |
| Expansion Slots | 1 x PCI |
| VGA | Integrated Intel Graphics Atom D525Max. shared memory: 256 MB |
| Storage | Southbridge2 xSATA 3 Gb/s ports support AHCI mode |
| LAN | PCIe Gb LAN |
| Audio | IDT73C 6-Channel High-Definition Audio CODEC |
| USB | 8 USB 2.0/1.1 ports (4 ports at mid-board, 4 ports at back panel) |
| ASUS Unique Features | ASUS CrashFree BIOS 3ASUS EZ Flash 2ASUS MyLogo 2AI NET 2Express Gate* The actual boot time is subject to hardware configurations and product models. |
| Back Panel I/O Ports | 1 x Parallel port1 x VGA1 x PS/2 Keyboard1 x PS/2 Mouse1 x LAN(RJ45) port4 x USB 2.0/1.11 x COM port6 -Channel Audio I/O |
| Internal I/O Connectors | 2 x USB connectors support additional 4 USB ports1 x CPU Fan connector1 x Chassis Fan connector1 x COM port header1 x Chassis Intrusion connector(optional)1 x TPM header (optional)1 x Front Panel connector1 x LVDS header1 x S/PDIF out header1 x High Definition front panel audio connector24-pin EPS 12V Power connector4-pin ATX 12V Power connector |
| BIOS | 8 Mb Flash ROM , AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5 |
| Accessories | User's manual1 x I/O Shield1 x SATA cable(s) |
| Support Disc | DriversASUS PC Probe IIAnti-virus software (OEM version)ASUS Update |
| Form Factor | Mini ITX Form Factor6.75 inch x 6.75 inch ( 17 cm x 17 cm ) |
