中央處理器prefix = o ns = "urn:schemas-microsoft-com:office:office" | INTEL ATOM330, 45NM 1.6g , L1 24KB,32KB, L2 512KB |
晶片組 | I945 , I82945G , IGMA950 {8M} 82801GB [ICH7/R] |
前側匯流排 | 533MHz |
記憶體 | 1 x DIMM, 2 GB, DDR2 800 Non-ECC,Un-buffered Memory |
擴充插槽 | 1 x PCI |
儲存功能 | 2 xSATA 3 Gb/s ports |
網路功能 | Realtek PCIE GBELANController |
音效功能 | Realtek ALC 662 ATISB600 6聲道High-Definition Audio CODEC |
USB | 6 USB 2.0 ports (2 ports at mid-board,2 ports at back panel) |
背板I/O埠 | 1 x D-Sub 1組PS/2鍵盤 1組RJ45網路孔 4組USB 2.0/1.1 8聲道音效I/O 1 x 25PIN LPt COM 1 X DB-9PIN sport |
內建I/O連接孔 | 2組USB連結support additional 2 USB ports 1組CPU風扇連結 1組 電源風扇連結 1 x Front Panel connector 1 x High Definition front panel audio connector 24-pin EPS 12V Power connector 1 x Chassis Intrusion connector |
體積 | Mini ITX規格 17.1 cm x 17.1cm ) |
